Arched Wing Gate HF-FI05
The Arched Wing Gate HF-FI05 is a stylish and high-security access control solution designed for environments that require both functionality and aesthetic appeal. Its arched wing design provides a modern and elegant look, while maintaining robust security features. Ideal for corporate offices, government buildings, transportation hubs, and luxury facilities, this gate offers smooth, efficient access while preventing unauthorized entry. It supports multiple authentication methods such as facial recognition, fingerprint scanning, IC/ID cards, and QR code scanning, ensuring a high level of security and flexibility. The HF-FI05 is perfect for locations that need secure access management without compromising on design.
Arched Wing Gate HF-FI05
Unique Appearance Design
The arched wing design of the HF - FI05 features an elegant and modern look, which can blend well with various architectural styles and decoration environments, adding a touch of sophistication to the entrance area.
High - Quality Materials
It is made of high - quality materials, ensuring durability and reliability. The box - type structure is sturdy, capable of withstanding daily use and potential impacts, while the wing is made of impact - resistant and scratch - resistant materials to maintain its appearance and functionality over time.
Efficient Passage Control
This wing gate enables efficient control of pedestrian traffic. It can quickly open and close the wings to allow pedestrians to pass through smoothly, with a relatively high passage rate, which helps to reduce congestion in high - traffic areas.
Accurate Sensor Technology
Equipped with advanced sensor technology, the HF - FI05 can accurately detect the presence of pedestrians, ensuring reliable operation. It can detect various situations such as pedestrians approaching, passing through, and tailing, and respond promptly to prevent unauthorized access and ensure the safety of passage.
Multiple Access Modes
It supports multiple access control modes, such as IC card, ID card, fingerprint recognition, facial recognition, and QR code scanning. This allows for flexible integration with different access control systems, meeting the diverse needs of different application scenarios and users.
Safety Protection Features
The product is designed with safety in mind. It has features such as anti - pinch protection, ensuring that pedestrians are not injured when the wings close. Additionally, it may have emergency release functions to allow for quick evacuation in the event of an emergency.
Low Noise Operation
The HF - FI05 operates with low noise, which is beneficial in environments where noise control is important, such as office buildings, hospitals, and schools. It provides a quiet and comfortable passage environment for users.
Easy Maintenance
With a modular design, the gate is easy to maintain and repair. Components can be easily accessed and replaced, reducing maintenance time and costs, and ensuring the continuous operation of the equipment.
product information
1.Physical Dimensions:L1400*W300*H980mm
2.Chassis material: 304 stainless steel,
3.Channel width(mm): 600
4.Gate opening and closing time: 0.8-1 second adjustable
5.Passing speed: 30 people/minute (normally open),25-30people/minute (normally closed)
6.Application environment: indoor, outdoor (shade)-10C70’C 7.Relative humidity: <90%, no condensation
8. Working temperature:-40~125°C
9. Working humidity: <90%, no condensation
10.Power supply:AC220±10%V ,50±10%HZ
10.Average power consumption(W): 100W
11.Input interface:standard switch signal
| Chassis material | SUS304 stainless steel |
| Working voltage | AC220±10%V 50±10%HZ |
| Power consumption | 100W |
| Dimensions | L1200*W300*H980mm |
Rotary rod transmission angle | 120° |
Rotary rod direction | one-way or two-way |
| Working environment | -10℃～70℃ |
| Gate opening and closing time | 0.8-1 second adjustable |
| Passing speed | 30 people/minute(normally open),25-30 people/minute (normally closed) |
The time required to enter the pass state after powering on | 2 seconds |
| Normal service life | Continuous rotation more than 5 million times |
| Gate opening angle | 90±5 |
| Noise | <50DB |
| Communication interface | Standard RS485 interface, 232 protocol, distance ≤1200 meters |
| Input interface | Relay switching signal or 12V level signal or 12V pulse signal with pulse width >100ms, drive current >10mA |
Control technology | Advanced motion drive algorithm technology |
Responding speed | 600RPM |
Communication Interface | Standard RS485 interface, 232 protocol, distance ≤1200 meters |
| Indication function | Red (alarm), green (work) indicator light |
Use/storage temperature | 45°C/-20°C~55°C |
Use/storage temperature | 40%~80%/0%~90% (no condensation) |
Noise | ＜50DB |
Vibration/impact resistance | 4.9m/s²/19.6m/s² |
| Altitude | ＜1000m |
| Atmospheric pressure | 86/106kpa |
| Voltage | DC5v±0.25 |
| Current consumption | 150mA |
| Responding speed | 600RPM |
| Output way | ZPulse |
| Operating temperature | -40°C~125°C |
| Storage temperature | -40°C~125°C |
Vibration resistant | 49m/s |
| Impact resistance | 980m/s |
Warranty and maintenance | We can provide warranty and maintenance for our products within a certain period of time. |
| Usage training | Provide user manuals and instructional videos, as well as online training. |
| Support technology development | our engineers to support during your development, and there is developing guide provided. |
| Customized services | Customized according to customer needs. |
| Office Buildings |
| Public Transportation Hubs |
| Commercial Complexes & Shopping Malls |
| Government & Institutional Facilities |
| Factories & Industrial Areas |
| Schools & Universities |
| Residential & Gated Communities |
| Stadiums & Event Venues |
| Hospitals & Medical Facilities |
| Data Centers & High-Security Zones |
Our turnstiles are packed in sturdy wooden crates, ensuring safe and efficient shipping. We deliver quality, both in products and packaging.
FAQ Schema
It’s made from 304 stainless steel, which is durable and resistant to corrosion.
The passage width is up to 600mm, suitable for most people and small items.
It supports facial recognition, fingerprint scanning, IC cards, QR codes, and NFC.
Yes, it’s designed for high-traffic places like airports, offices, and stadiums.
Yes, the anti-reverse function stops anyone from sneaking in after an authorized person.
