Vertical Swing Gate HF-SG05
the Vertical Swing Gate HF-SG05, a premium access control solution designed for both indoor and outdoor environments. Built with a high-strength 304 stainless steel chassis, this swing gate offers enhanced durability, stability, and security compared to standard gate designs. Its larger chassis structure ensures better resistance to impact, making it an ideal choice for areas requiring high safety and reliability.
our factory
Our factory is working hard to carefully package and ship our high-quality turnstiles and speed gates to customers worldwide! Each unit is securely packed to ensure safe transportation and flawless performance upon arrival.
At HFSECURITY, we are committed to delivering top-tier access control solutions with precision, durability, and reliability. Stay tuned for more updates as we bring advanced security technology to your doorstep!
Robust and Durable Build
- Constructed from 304 stainless steel, ensuring corrosion resistance and long-lasting durability.
- Larger chassis design enhances overall stability and security.
✅ Indoor & Outdoor Compatibility
- Engineered for both indoor and outdoor use, providing flexible deployment options.
- Weather-resistant materials ensure reliable performance in various environments.
✅ Smooth and Safe Operation
- Intelligent swing arm mechanism allows for seamless pedestrian passage.
- Designed with anti-clamping sensors to prevent injuries and ensure user safety.
✅ Advanced Security Integration
- Supports RFID, biometric recognition (fingerprint, facial, palm vein), QR code scanning, and other authentication methods.
- Effectively prevents unauthorized access and enhances access control efficiency.
✅ High-Traffic Efficiency
- Fast opening and closing speeds for efficient pedestrian flow management.
- Ideal for commercial buildings, office spaces, public transportation hubs, and high-security areas.
✅ Emergency & Fail-Safe Functionality
- In the event of a power failure, the gate automatically unlocks, ensuring a free passage mode for quick evacuation.
product information
This is the heading
The Vertical Swing Gate HF-SG05 is a robust and reliable access control solution designed for environments that demand stability and security. With its larger, more substantial chassis, this swing gate offers enhanced durability and a solid presence, making it ideal for both indoor and outdoor use. Built with premium 304 stainless steel, the HF-SG05 combines strength, functionality, and advanced features to provide a seamless and secure access control experience.
| Chassis material | 304 Stainless Steel |
| product type | speed gate |
| Working voltage | AC220±10%V 50±10%HZ |
| channel width | 600-900mm |
| Power consumption | 100W |
| Rotary rod transmission angle | 120° |
| Working environment | -40~125℃ |
| Gate opening and closing time | 0.8-1 second |
| adjustablePassing speed | 30 people/minute(normally open),25-30 people/minute(normally closed) |
| The time required to enter the pass state after powering on | 2 seconds |
| Normal service life | Continuous rotation more than 5 million times |
| Gate opening angle | 90±5 |
| Noise | <50DB |
| Communication interface | Standard RS485 interface, 232 protocol, distance ≤1200 meters |
| Control technology | Speedgate’s new multi-function self-test motherboard |
| Responding speed | 600RPM |
| Communication Interface | Standard RS485 interface, distance＜1200 meters |
| Indication function | Red (alarm), green (work) indicator light |
| Use/storage temperature | 45°C/-20°C~55°C |
| Use/storage temperature | 40%~80%/0%~90% (no condensation) |
| Noise | ＜50DB |
| Vibration/impact resistance | 4.9m/s²/19.6m/s² |
| Atmospheric pressure | 86/106kpa |
| Voltage | DC5v±0.25 |
| Current consumption | 150mA |
| Responding speed | 600RPM |
| Output way | ZPulse |
| Operating temperature | -20°C~50°C |
| Storage temperature | -20°C~50°C |
| Vibration resistant | 49m/s |
| Impact resistance | 980m/s |
Control technology | Advanced motion drive algorithm technology |
Responding speed | 600RPM |
Communication Interface | Standard RS485 interface, 232 protocol, distance ≤1200 meters |
| Indication function | Red (alarm), green (work) indicator light |
Use/storage temperature | 45°C/-20°C~55°C |
Use/storage temperature | 40%~80%/0%~90% (no condensation) |
Noise | ＜50DB |
Vibration/impact resistance | 4.9m/s²/19.6m/s² |
| Altitude | ＜1000m |
| Atmospheric pressure | 86/106kpa |
| Voltage | DC5v±0.25 |
| Current consumption | 150mA |
| Responding speed | 600RPM |
| Output way | ZPulse |
| Operating temperature | -40°C~125°C |
| Storage temperature | -40°C~125°C |
Vibration resistant | 49m/s |
| Impact resistance | 980m/s |
| Operating Voltage | DC24V |
| Power | 21W |
| Torque | 100Nm |
| Swing arm | 304 Stainless Steel |
| Material | 304 Stainless Steel |
| Thickness | 8-12mm |
| Length | 275-400mm |
Our turnstiles are packed in custom wooden crates, designed for safe and efficient delivery. We ensure your product arrives in perfect condition.
With its superior durability, high security, and flexible deployment, the Vertical Swing Gate HF-SG05 is the perfect choice for businesses and institutions seeking a reliable, modern, and efficient access control solution. Upgrade your security with HF-SG05 today!
FAQ Schema
The swing gate supports multiple authentication methods including card swipe, QR code scanning, fingerprint recognition, and facial recognition.
The swing gate uses advanced sensors to ensure that only one person can pass through at a time. If a person tries to follow closely behind without proper authentication, the gate will prevent entry.
Yes, our swing gates are highly versatile and can be used in various high-traffic areas like shopping malls, train stations, airports, and office buildings.
The swing gate is powered by a reliable electrical system designed for continuous operation in high-traffic environments.
Yes, the swing gate is designed for easy installation and can be configured to suit different operational needs.
Yes, it can be customized for one-way or two-way access depending on your needs.
The swing gate uses a smooth, silent mechanism that ensures minimal noise during operation, making it ideal for use in public spaces.
The swing gate requires minimal maintenance. Regular cleaning and occasional checks to ensure smooth operation are recommended.
